- Microcontroller design
- Voltage sensing Unit
- Phase faiture Protection
- Reverse phasing protection
- Base mountable
- Unbalance (fixed unbalance setting )
- Auto Reset
- 2 C/O Output Relay
- fixed UV/OV setting
- Bypass facilities Available
| Supply voltage | 415 VAC , 50Hz ± 5% |
| Output Relay Contact | 2 CO |
| Unbalanced trip Setting | 45V ± 10 VAC VAC(fixed) |
| Bypass system | yes |
| Trip time delay for unbalance | 1 to 2 sec ± 0.5 sec |
| Resetting mode | Auto |
| Output Contact Rating | 5 Amp 230 V AC (Resistive) |
| Under Voltage (low voltage) | 320 VAC ± 5% |
| Over voltage (High voltage) | 480 VAC ± 5% |
| Weight | 0.577 gms |
| Dimension (mm) | |
| -Dimension (HXWXD) | (144 X 95 X 96) |
| -Base mounting | Yes |
- Agricultral Pump starters
- Machine tools
- Injection molding m/c
- 3 Ph Spilit AC machines
- Valve Actuator motor
- Submercible pomp
- Main Powers Supply / distribution panel board
